Link CANLTW - CAN Connection Cable for WireIn ECU’s (6Pin CAN)
Original price
$0
Original price
$50.00
-
Original price
$50.00
Original price
Current price
$50.00
$50.00
-
$50.00
Current price
$50.00
Required to add CAN communication to WireIn ECU's which have CAN accessible via the 6Pin round CAN connector on the front of the ECU.
Compatible ECU's:
G4X/G4+ Xtreme (CAN1)
G4X/G4+ Fury (CAN1)
G4+ Force (CAN1)
G4+ Thunder (CAN1)
Specs
DTM4 Male to LTW 6Pin. 12V & GND Flying Leads. CAN Loom Length 300mm (Flying lead length 500mm)
DTM4 Pin Out
Pin 4: CAN H
Pin 3: CAN L
Pin 2: Ground
Pin 1: 12V
Compatible ECU's:
G4X/G4+ Xtreme (CAN1)
G4X/G4+ Fury (CAN1)
G4+ Force (CAN1)
G4+ Thunder (CAN1)
Specs
DTM4 Male to LTW 6Pin. 12V & GND Flying Leads. CAN Loom Length 300mm (Flying lead length 500mm)
DTM4 Pin Out
Pin 4: CAN H
Pin 3: CAN L
Pin 2: Ground
Pin 1: 12V
